- Size: 0.1
- Place of Origin: China
- Brand Name: RECI
- Model Number: RC-B20FP
- Weight: 40.000 kg
Technical parameter
Model | RC-B10FP/20FP/30FP/50FP | RC-B10F/20F/30F/50F | |
Laser power | 10W 20W 30W 50W | 10W 20W 30W 50W | |
Laser wavelength | 1064nm±10nm | ||
Q-frequency | 20KHz~100KHz | ||
Divergence | 0.3mard | ||
Marking range | 110*110mm /205*205mm/290*290mm | ||
/Minimum line width | 0.01mm | ||
/Minimum character | 0.1mm | ||
Marking speed | 10000mm/s | ||
Marking depth | 0~0.5mm | ||
Engraving line speed | ≤7000mm/s | ||
Repeatability accuracy | ±0.001mm | ||
Beam quality | M2:1.2~1.8 | ||
Marking format | Graphics,text,barcodes, two-dimensional code, automatically marking the date,batch number,serial Number,frequency,etc. | ||
Graphic format supported | bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc | ||
Working voltage | 220V±10%/50Hz/4A | ||
Unit power | ＜0.5kw | ||
Use of the environment | Clean and dust free or dust less | ||
Working condition:Humidity | 5%-75%，Free of condensed water | ||
Laser module life | ＞100000hours | ||
The whole life | More than 15 years | ||
Packing size | 760*230*550mm | 850*670*950mm | |
Net Weight | 45kg | 80kg | |
Applicable industries
Mobile phone keypad, plastic translucent keys, electronic components, integrated circuits (IC), electrical appliances, communication products, sanitary ware, tools, accessories, knives, eyeglasses and clocks, jewelry, auto parts, luggage buckle, cooking utensils, stainless steel products and other industries.
Applicable materials
Metals (including rare metals), engineering plastics, electroplating materials, coating materials,coating materials, plastics, rubber, epoxy resin, ceramic, plastic, ABS, PVC, PES, steel, titanium, copper and other materia
Samples
Craft＆gift marking
Knife tool marking
/Mobile phone marking
Flange marking
Ceramic marking
Wood products marking
