- Size: 3.7*2.24*1.86
- Place of Origin: China
- Brand Name: RECI
- Model Number: RC-G1325P
- Weight: 1500.000 kg
1.The Suitable material:
Cutting or Engraving on Iron Plate, Aluminum sheet, Galvanized Sheet, Stainless,Titanium plates etc.
2.The application industries:
Cars, motorcycles, pressure vessels, chemical machinery, nuclear industry, general machinery, engineering machinery, steel structure, shipbuilding and other industries.
The cnc plasma cutting machine spare Parts pictures:
START Control system
Machine features:
1. START Control system (Option:DSP, MACH3)
2. Thermadyne 60A plasma power (Option:Chinese Power)
3. Automatic arc pressure adjustable
4. Stepping drive and motor(Option: Yaskawa Servo motors)
5. UCANCAM Software
6. HIVIN Linear Guide
7. Wooden box package
8. Thicken cast steel structure
9. Aluminum alloy gantry
10.YAKO 2608 drives
11.Toothed bar table
- Size: 3.7*2.24*1.86
- Place of Origin: China
- Brand Name: RECI
- Model Number: RC-G1325P
- Weight: 1500.000 kg
Parameters:
Item | Parameters
| |
1 | Working area | 1300*2500*200mm |
2 | Processing thickness | 0.5-25mm(depends on customer's request) |
3 | Cutting speed | 0-8000mm/min |
4 | Input voltage | 380V 3PH |
5 | Power frequency | 50HZ |
6 | Plasma Power | 60A |
7 | Interface | USB |
8 | Working Form | Untouched arc striking |
9 | Machine Outer Size | 3250*1950*1750mm |
